CKZ6953N3 |
| Overall specification |
overall lenthmm |
9540 |
| overall widthmm |
2500 |
| overall heightmm |
3050, 3250 |
| wheelbasemm |
4700 |
| Engine specification |
engine model |
EQ6100N-30 |
NQ150N |
| displacementml |
5420 |
5638 |
| MAX.outputkW/rpm |
95/3000 |
107/2600 |
| Max.torqueN.m/rpm |
350/1000-1400 |
520/1200-1600 |
| performance specification |
F/R overhangmm |
2250/2590 |
| MAX.total masskg |
11650 |
| loading passenger+driver |
62,53/19-40 |
| Approach/Departure degree |
10/9 |
| MAX.speedkm/h |
70 |
| F/R treadmm |
2020/1800 |
| fuel |
CNG |
| chassis specification |
chassis model |
EQ6900TN3AC1 |
| transmission |
Mechanical, remote control,5 forward speed, 1 reverse speed |
| steering system |
7.0 recirculating ball streeing |
| brake system |
dual circuir pneumatic brake system,energy storage parrking brake |
| interior treamming |
interrior treamming |
air passege, side curtain,carrier,Polyester foaming instrument panel engine cover, |
| seat |
29+1 |
| A/C system |
28000kcal/hoptional roof independent A/C |
| heating and defrosting |
optional water-warm defrosting | |
